SIM68MB
SIMCom提供了一个高性能和可靠的GNSS模块-SIM68MB。这是一个SMT类型的独立GPS L1频率和BD2 GNSS模块，带有MTK的高灵敏度导航引擎，允许客户以较低的功耗实现行业的高灵敏度、准确度和首次修复时间（TTFF）。
鹏程万里 海纳百川 创智未来 信达天下
专注芯片行业15年 品质高于一切 信任铸就共赢
全国销售服务热线0755-83258455
全国销售服务热线0755-83258455
服务热线0755-83258455
首页 > 产品中心 > SIMCom 芯讯通(代理) > GNSS模组
SIMCom提供了一个高性能和可靠的GNSS模块-SIM68MB。这是一个SMT类型的独立GPS L1频率和BD2 GNSS模块，带有MTK的高灵敏度导航引擎，允许客户以较低的功耗实现行业的高灵敏度、准确度和首次修复时间（TTFF）。
Mechanical data •Dimensions: 10.1*9.7*2.5mm •Weight: 0.5g Features •Support GPS/BD2 •Support EASYTM self-generated orbit prediction •Support EPOTM orbit prediction •Support SBAS ranging (WAAS, EGNOS, GAGAN, MSAS) •Support DGPS (RTCM) •Support Jamming Removing •Low-noise amplifier has been integrated Interfaces •Serial interfaces UART •Digital I/O EINT0 input Pulse-per-second (PPS) •Protocols NMEA PMTK PSIM Support product •SIM68 EVB KIT with USB V2.0 full speed interface | Performance data •Receiver type 33tracking/99 acquisitionchannel GNSS receiver •Max. update rate 10Hz •Sensitivity1 Tracking:-165 dBm Reacquisition:-160 dBm Cold starts:-148 dBm •Time-To-First-Fix2 Cold starts:28 s Warm start:26 s Hot starts:<1s EPO Assist:13s（CTTFF) • Accuracy Automatic Position3:<2.5m CEP Speed4:0.1m/s •Operation temperature5: -40℃~+85 ℃ | Electrical data •Power supply: 2.8V~4.3V •Backup power: 2.3V~4.6V •Power consumption2,6 Acquisition: 25mA Tracking: 18mA AlwaysLocateTM: 340uA Backup 14uA •Antenna type Active and passive •Antenna power External or internal VCC_RF Approvals • RoHS\REACH\CE(RED) ------------------ 1.Demonstrated in lab 2.All SV @ –130 dBm, GPS&BD2 mode 3.50% 24 hr static, -130dBm,GPS&BD2mode 4.50%@ 30m/s 5.When at -40℃~ -30℃,the sensitivity will be somewhat worse 6. @2.8V with a passive antenna |
